Wing

SOC:	Allwinner IK316/H616/H313/IK318/H618
CPU:	Quad Core ARM Cortex-A53
GPU:	ARM Mali-G31, OpenGL ES 1.0/2.0/3.2, Vulkan 1.1, OpenCL 2.0
DRAM:	1GB
EMMC:	8GB
OS:	Android 10.0
RJ45:	100M
WIFI:	2.4G/5GHz + WiFi6 + BT5.0

Inquire Now Next Product Download

Description

Diagram

E-commerce

Product Description

1、Elegant and Compact, Stylish and Portable: Its ultra-lightweight design makes it easily put into the pocket, and seamlessly blends into a variety of scenes.

2、Massive storage, Smooth experience: The combination of large-capacity RAM and ROM ensures that the device can load and run quickly.

3、Smart dual-band, ultra-fast transmission: Supports both 2.4G and 5G bands with the latest WiFi 6 standard for faster transmission speeds and lower latency, ensuring a stable network connection at all times.

4、Exceptional audio-visual, Immersive enjoyment: 4K ultra HD video delivers smooth, lifelike visuals that make you feel as if you're in a cinematic masterpiece, offering an unprecedented level of picture quality.

Basic Parameters
Model Number:	wing
Processor:	Allwinner IK316/H616/H313/IK318/H618
Processor Core:	Quad Core ARM Cortex-A53
RAM:	DDR3 1GB (1.5GB, 2GB, 3GB, 4GB Optional; 3GB, 4GB Limited to H616, IK318, and H618)
ROM:	EMCP-EMMC 8GB (16GB, 32GB, 64GB, 128GB Optional)
Operation System:	Android 10 (Android 12 Optional; Limited to IK318 and H618)
WIFI:	802.11 a/b/g/n/ac/ax (2.4G + 5G + WiFi6)
Ethernet:	100M
I/O
Video/Audio Input:	HDMI 2.0
Peripheral Interface:	USB 2.0 HOST x1, USB-TYPE-C OTG x1, TF x1
Power Interface:	DC 5V@1.5A (TYPE-C JACK)
Other Interface:	IR receiver
Other Attributes
Place of Origin:	Guangdong, China
Support Resolution:	4K
Brand Name:	IK
Type:	Android Box
Certification:	CE, ROHS, FCC
OEM/ODM:	Support Custom LOGO
Warranty:	1 year
